Brass Insert

Product Description

Special Features » Threads as per International Go & Not Go Standards.
of Brass Inserts : » Deep Groove for maximum Pull Out Resistance.
» Inner Diameter (I/D) after Threads with very close tolerance to prevent unnecessary flush to enter into the brass inserts.

Material : » Free Cutting Brass IS 319 ( I ) / BS 249 / CZ121Pb3
» Free Cutting Brass IS 319 ( II ) / CZ124
» Free Cutting Brass IS 319 ( III ) / BS 249
» High Grade Free Cutting Brass
» Any Special Brass Material Composition As Per Customers Requirement.

Threads : » ISO Metric (MM) / BA / BSW / BSP / BSPT / BSF / BSB / UNC / UNF / UNEF / NPT / NPS / Specified Threads Any threads as per client specification.

Size : » Sizes available as per Custom Designs and requirements.

Finish & Coating : » Brass Natural, Electro Tinned, Nickel, Chrome, Led, Silver, Gold, Zinc Blue or any special finish/plating as per customer specifications.

We are the leading manufacturer of Brass threaded inserts for plastics industries, communication equipment's, automotive industries, electrical, Wiring device cases, plastic injection, wood, and laptop etc. We offer a full line of brass inserts for all methods of installation, including: ultrasonic, heat, thermal, press-in and mold-in. Although we produce various brass inserts as per custom design & specification, we have standard series of Threaded Inserts such as Straight Hole, Blind (Closed bottom), Collar Inserts, Ultrasonic, Press in, Tri Slotted Inserts etc.

Any type of Brass insert can be developed and supplied exactly as per customer specifications.
